Unbeatable and Revolutionary Anti-Kink
Performance
• Passes 34", 24" and 18", doorway kink test.
• Loops to 11" before kink ensuring no line
failure or loss of flow in the tightest of
environments, even at 100 PSI line pressure.
Extraordinary Abrasion Resistance
• Our innovative ARMOUR JACKET coating
demonstrates virtually no sign of wear when
subjected to the standard FM & UL Abrasion
test. Firepower II is available with this new
coating in yellow, red, orange, blue, green
and tan.
Significantly Reduced Drag Resistance
• Measurably less drag resistance over other
conventional hose causing less strain on
users.
Superb Water Resistant Jacket
• Our innovative ARMOUR JACKET coating
and uniquely woven jacket drastically
reduces water pickup over conventional
hose; therefore significantly reducing overall
weight of a hose line in use.
• Special coating provides enhanced protection
from chemicals.
Outstanding Heat Resistance
Performance
• Six times more heat resistance over other
conventional hoses when subjected to the
Angus Heated Constant Load Test.
• Through-the-weave rubber inner liners
withstand very high temperatures. TPU liners
will fail long before rubber liners when
subjected to direct heat.
Specialized Construction & Physical
Characteristics
• Through-the-weave rubber liner providing
incredible puncture resistance, ultimate
resistance to heat and maintains low friction
loss performance.
• Uniquely woven synthetic outer jacket
providing tough abrasion resistance, low drag
resistance and incredible anti-kink
performance.
• Light weight hose makes it easy to use and
very easy to roll with an extremely compact
rolled coil diameter.
• Provides outstanding performance for CAFS
operations.
Angus Firepower II
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 400 2800 800 5600 1200 8400 1-15/16 49 14 6.3 20 508
1-3/4 50 400 2800 800 5600 1200 8400 2-1/6 55 15 6.8 21 533
2-1/2 65 400 2800 800 5600 1200 8400 3 76 27.5 12.5 22 559
* Weight is uncoupled
