Soot Blower Sets
GRAPH-LOCK® Sets
Construction: Premium density GRAPH-LOCK®
center rings (87.5 lbs/ft3 [1,400 kg/m3])
with 1303-FEP or 98 end rings
Temperature: To +850°F (+455°C) atmosphere,
+1,200°F (+650°C) steam
TORNADO PACK™ F1
Construction: Style 127-AFP: INCONEL wire rein-
forced carbon over homogeneous core
Temperature: To +650°F (+345°C) atmosphere,
+1,200°F (+650°C) steam
TORNADO PACK™ F3
Construction: Style 1298: INCONEL wire reinforced
PBI††† over carbon yarn core
Temperature: To +850°F (+455°C) atmosphere,
+1,200°F (+650°C) steam
TORNADO PACK™ F5
Construction: Style 1303-FEP: INCONEL wire rein-
forced fexible graphite
Temperature: To +850°F (+455°C) atmosphere,
+1,200°F (+650°C) steam
Exceptional reliability
¦ Rugged materials for
extended service life
¦ INCONEL†† wire
reinforcement with-
stands high
temperatures and
pressures
¦ Die-formed rings en-
sure accurate ft and
simple installation
¦ Effcient conical
design allows
outstanding sealing
at low gland loads
¦ Standard sizes for Diamond Power, Copes Vulcan
and other soot blowers
Crown Bush Pump
Sealing System
Lower your operating costs
¦Signifcantly reduce fush water usage
¦Extend packing life
¦Reduce sleeve wear
¦Flush water distribution optimised to keep contami-
nants away from the gland packing
¦Stainless Steel Crown Bush fow control device
resists erosion from abrasive contaminants
¦Non-metallic construction available for non-abrasive
duties
¦Split version available
Applications
¦Pulp and paper
¦Mining
¦Mineral Sands
¦Alumina Refning
¦Coal Washing
