6/09
Size Range
from 2 in. - 120 in. diameter pipe sizes (tube sizes also available).
Single and multi-ply
Alloys
• Stainless steels including -
T304, T304L, T309, T310, T321, T316, T316L
• Nickel alloys including -
400, 600, 625, 625LCF, 800, 800H, Nickel 200, C276
• Other alloys are available upon request
Pre-Engineered Expansion Joints
are 15, 50, 150 or 300 psi bellows, stocked and ready for rapid shipment.
Accounting for many basic expansion joint applications, pre-engineered designs include:
• Standard Bellows
• Unrestrained Single
• Limit Single
Pre-Engineered expansion joints are available in sizes ranging from 2 in. - 30 in. and in 321 and 316
stainless steel.
Pre-Engineered expansion joints can be constructed using any type of end fitting or accessory. Standard
accessories include stainless cover, single drop-in liner, single welded liner, or custom metal tags.
Custom-Designed Expansion Joints
are available in an array of alloys and end fittings to suit any
expansion joint application. Because of their many options, Custom-Designed expansion joints are designed
to suit specific needs and are engineered through our Inside Sales Department.
Custom-Designed expansion joints are available in sizes ranging from 2 in. - 120 in. and all alloys
(as listed above).
Custom-Designed expansion joints can be constructed using any type of end fittings or product options
including:
• 321 stainless steel cover
• Single welded liner
• Telescoping welded liner
• Single drop-in liner
• Smooth transition/Full-flow liner
• Telescoping drop-in liner
• Custom metal tag
Rapid Deliveries
-
An aggressive material stocking program provides exceptional service with
the best standard delivery time. Expedited next-day deliveries are available upon request.
3-D CAD Drawings
- Available upon request with any inquiry.
Pressure
from full vacuum to 3000 psi
Temperature
range -450º F. to 2000º F.
• Tied Single
• Unrestained Universal
• Tied Universal
Certifications
-
ABS, ASME VIII, ASME IX, B31.1, and B31.3
All expansion joints are designed and manufactured to EJMA standards.
S p e c i f i c a t i o n s
D e s i g n s
