Part No.
ID” OD” Ply WP
psi
202V-01000-00 1”
1.362 4 170
202V-01180-00 1 1/8” 1.487 4 160
202V-01140-00 1 1/4” 1.612 4 150
202V-01380-00 1 3/8 1.737 4 135
202V-01120-00 1 1/2” 1.862 4 130
202V-01340-00 1 3/4” 2.112 4 118
202V-01870-00 1 7/8” 2.237 4 112
202V-02000-00 2”
2.362 4 110
202V-02180-00 2 1/8” 2.487 4 106
202V-02140-00 2 1/4” 2.612 4 103
202V-01380-00 2 3/8” 2.737 4 100
202V-02120-00 2 1/2” 2.862 4 94
202V-02340-00 2 3/4” 3.112 4 84
202V-02780-00 2 7/8” 3.23 4 80
202V-03000-00 3”
3.362 4 79
202V-03180-00 3 1/8” 3.48 4 77
Part No.
ID”
ww
OD” Ply WP
psi
202V-03180-00 3 1/8” 3.48 4 77
202V-03140-00 3 1/4” 3.16 4 74
202V-03120-00 3 1/2” 3.862 4 66
202Z-04000-00 4”
4.362 4 58
202V-04120-00 4 1/2” 4.862 4 56
202V-05000-00 5 ”
5.362 4 52
202V-05120-00 5 1/2” 5.862 4 50
202V-06000-00 6 ”
6.362 6 80
202V-06580-00 6 5/8” 6.99 6 75
202V-07000-00 7”
7.5 6 70
202V-08000-00 8”
8.5 6 60
202V-10000-00 10”
10.5 6 55
202V-12000-00 12”
12.5 6 50
202V-14000-00 14”
14.5 6 40
202V-16000-00 16”
16.6 6 30
202V-18000-00 18”
18.5 6 25
E
xtender 350 Silicon Wet Exhaust hose
is a softwall flexible hose designed
to provide maximum service life in pleasure and commercial marine exhaust
applications. Hose exceeds SAE J2006.
Cover:
Metallic Blue
Construction:
4 ply polyester to SAE J2006 standards
Temperature range:
-65º to +350ºF (-54º to +177ºC)
Working Pressure
: 25% of burst pressure
Warranty:
10 years
Series 202V 350º
Softwall Exhaust Hose
Series 202X 500º Softwall
Exhaust Hose (aramid fabric)
Extender 500 202X (500ºF) change V in part no. to X—all other data the same
Extender 500 252X (500ºF) change V in part no. to X—all other data the same
Minimum bend radius is 4 times the ID in inches
Part No.
ID”
OD” Ply WP
psi
252V-00340-00 3/4”
1.04 2
90
252V-00780-00 7/8”
1.16 2
88
252V-01000-00 1”
1.29 2
85
252V-01180-00 1 1/8” 1.41 2 80
252V-01140-00 1 1/4” 1.54 2 76
252V-01380-00 1 3/8” 1.66 2 68
252V-0120-00 1 1/2” 1.79 2 66
252V-01340-00 1 3/4” 2.04 2 60
252V-01780-00 1 7/8” 2.16 2 57
252V-02000-00 2”
2.29 2 56
252V-02180-00 2 1/8” 2.41 2
52
252V-02140-00 2 1/4” 2.54 2
51
252V-02120-00 2 1/2” 2.79 2
43
252V-02340-00 2 3/4” 3.04 2
42
252V-02780-00 2 7/8” 3.16 2 40
252V-03000-00 3”
3.29 2 39
Extender 350 Silicon Wet Exhaust hose
is a hardwall highly flexible
hose designed to provide maximum service life in pleasure and commercial
marine exhaust applications. Hose exceeds SAE J2006
Cover:
Metallic Blue
Construction:
2 Ply polyester to SAE J2006 standards
Temperature range:
-65º to +350ºF (-54º to +177ºC)
Working Pressure:
25% of Burst Pressure
Warranty:
10 years
Series 252V 350ºF Hardwall
Exhaust Hose (aramid fabric)
Series 252X 500º Hardwall
Exhaust Hose (aramid fabric)
Part No.
ID“
OD”
Ply WP
psi
252V-03180-00 3 1/8”
3.29
2 38
252V-03120-00 3 1/2”
3.79
2 33
252V-03340-00 3 3/4”
4.04
2 30
252V-04000-00 4”
4.362 4 58
252V-04120-00 4 1/2”
4.862 4 56
252V-05000-00 5 ”
5.362 4 52
252V-5120-00 5 1/2”
5.862 4 50
252V-06000-00 6 ”
6.362 4 46
252V-06580-00 6 5/8”
6.987 4 41
252V-07000-00 7”
7.362 4 35
252V-08000-00 8”
8.362 4 30
252V-10000-00 10”
10.362 4 24
252V-12000-00 12”
12.362 4 20
252V-14000-00 14”
14.362 4 16
252V-16000-00 16”
16.362 4 13
252V-18000-00 18”
18.362 4 10
Exhaust
hardwall softwall •
Hump Hose
single hump double h
