O-Ring Tube, Male, Swivel, 45 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTM45-0606 50703-0606 5/16 7.90 5/8-18 0.87
22
0.83
21
AC-OTM45-0808 50703-0808 13/32 10.30 3/4-18 0.98
25
0.94
24
AC-OTM45-1010 50703-1010 1/2 12.70 7/8-18 1.06
27
1.26
32
AC-OTM45-1210 50703-1210 5/8 15.90 7/8-18 1.18
30
1.50
38
AC-OTM45-1212 50703-1212 5/8 15.90 1 1/16-16 1.18
30
1.50
38
O-Ring Tube, Male, Swivel, 90 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTM90-0606 50705-0606 5/16 7.90 5/8-18 1.61
41
1.06
27
AC-OTM90-0608 50705-0608 5/16 7.90 3/4-18 1.89
48
1.26
32
AC-OTM90-0806 50705-0806 13/32 10.30 5/8-18 1.89
48
1.26
32
AC-OTM90-0808 50705-0808 13/32 10.30 3/4-18 1.89
48
1.26
32
AC-OTM90-1010 50705-1010 1/2 12.70 7/8-18 2.13
54
1.50
38
AC-OTM90-1012 50705-1012 1/2 12.70 1 1/16-16 2.24
57
1.77
45
AC-OTM90-1210 50705-1210 5/8 15.90 7/8-18 2.24
57
1.77
45
AC-OTM90-1212 50705-1212 5/8 15.90 1 1/16-16 2.24
57
1.77
45
O-Ring Tube, Male, Swivel, Long Pilot
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTMLP-0606 50720-0606 5/16 7.90 5/8-18 1.61
41
1.06
27
AC-OTMLP-0808 50720-0808 13/32 10.30 3/4-18 1.89
48
1.26
32
AC-OTMLP-1010 50720-1010 1/2 12.70 7/8-18 2.13
54
1.50
38
AC-OTMLP-1210 50720-1210 5/8 15.90 7/8-18 2.24
57
1.77
45
O-Ring Tube , Male, Swivel, R134a Valve
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
AC-OTM134V-0606 50730-0606 5/16 7.90 5/8-18
1.69
43
0.63
16
AC-OTM134V-0808 50730-0808 13/32 10.30 3/4-18
1.77
45
0.63
16
AC-OTM134V-1010 50730-1010 1/2 12.70 7/8-18
2.36
60
0.51
13
AC-OTM134V-1210 50730-1210 5/8 15.90 7/8-18
2.36
60
0.51
13
AC-OTM134V-1212 50730-1212 5/8 15.90 1 1/16-16
2.52
64
0.51
13
Picture Not Available
One Source, One System, One Solution.
www.hydraulics.goodyear.com
Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
– 13 –
'AC' (Crimp) FITTINGS
For use with GALAXY G4826 (5/16"-5/8") & G4867 (3/4") Hose
