One Source, One System, One Solution.
www.hydraulics.goodyear.com
Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
Flareless Tube, Male, Metric
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-FTMM-0608 54240-0608 5/16 7.90 5/8-18
2.44
62
GC-FTMM-0812 54240-0812 13/32 10.30 3/4-16
2.56
65
GC-FTMM-1015 54240-1015 1/2 12.70 7/8-14
3.31
84
Ford Spring Lock, Female
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-FSLF-0606A 54300-0606A 5/16 7.90 FSL-06
2.52
64
GC-FSLF-0608A 54300-0608A 5/16 7.90 FSL-08
2.52
64
GC-FSLF-0808A 54300-0808A 13/32 10.30 FSL-08
2.76
70
GC-FSLF-1010A 54300-1010A 1/2 12.70 FSL-10
2.95
75
GC-FSLF-1210A 54300-1210A 5/8 15.90 FSL-10
2.95
75
GC-FSLF-1212A 54300-1212A 5/8 15.90 FSL-12
2.95
75
Ford Spring Lock, Female, 45 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-FSLF45-0606A 54303-0606A 5/16 7.90 FSL-06 1.30
33
1.50
38
GC-FSLF45-0608A 54303-0608A 5/16 7.90 FSL-08 1.30
33
1.50
38
GC-FSLF45-0808A 54303-0808A 13/32 10.30 FSL-08 1.30
33
0.94
24
GC-FSLF45-1010A 54303-1010A 1/2 12.70 FSL-10 1.42
36
1.26
32
GC-FSLF45-1210A 54303-1210A 5/8 15.90 FSL-10 1.42
36
1.26
32
GC-FSLF45-1212A 54303-1212A 5/8 15.90 FSL-12 1.42
36
1.26
32
Ford Spring Lock, Female, 90 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-FSLF90-0606A 54305-0606A 5/16 7.90 FSL-06 2.13
54
1.61
41
GC-FSLF90-0608A 54305-0608A 5/16 7.90 FSL-08 2.13
54
1.61
41
GC-FSLF90-0808A 54305-0808A 13/32 10.30 FSL-08 2.44
62
1.73
44
GC-FSLF90-1010A 54305-1010A 1/2 12.70 FSL-10 2.52
64
2.01
51
GC-FSLF90-1210A 54305-1210A 5/8 15.90 FSL-10 2.52
64
2.01
51
GC-FSLF90-1212A 54305-1212A 5/8 15.90 FSL-12 2.52
64
2.01
51
Picture Not Available
Picture Not Available
Picture Not Available
Picture Not Available
– 18 –
COOL CLIP
™
FITTINGS
For use with GALAXY
®
G4890 Hose
