Hose Mender, Tee
HOSE ID 1&2 HOSE ID 3 DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM INCH MM INCH MM INCH MM INCH MM
GC-HMT-0606 54380-0606 5/16 7.90 5/16 7.90 0.87 22 1.73 44
GC-HMT-0808 54380-0808 13/32 10.30 13/32 10.30 0.94 24 1.89 48
GC-HMT-1010 54380-1010 1/2 12.70 1/2 12.70 1.38 35 2.01 51
GC-HMT-1210 54380-1210 5/8 15.90 1/2 12.70 1.38 35 2.01 51
GC-HMT-1212 54380-1212 5/8 15.90 5/8 15.90 1.38 35 2.24 57
O-Ring Face Seal, Female, Swivel
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OFFX-0606 54430-0606 5/16 7.90 11/16-16 1.42 36
GC-OFFX-0808 54430-0808 13/32 10.30 13/16-16 1.61 41
GC-OFFX-1010 54430-1010 1/2 12.70 1-14 2.13 54
GC-OFFX-1212 54430-1212 5/8 15.90 1 3/16-12 2.36 60
O-Ring Face Seal, Female, Swivel, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OFFX90-0606 54435-0606 5/16 7.90 11/16-16 1.14 29 0.59 15
GC-OFFX90-0808 54435-0808 13/32 10.30 13/16-16 1.34 34 0.79 20
GC-OFFX90-1010 54435-1010 1/2 12.70 1-14 1.57 40 0.98 25
GC-OFFX90-1212 54435-1212 5/8 15.90 1 3/16-12 1.81 46 1.18 30
O-Ring Insert Male
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OIM-0606 54500-0606 5/16 7.90 5/8-18 2.44 62
GC-OIM-0808 54500-0808 13/32 10.30 3/4-16 2.56 65
GC-OIM-1010 54500-1010 1/2 12.70 7/8-14 1.77 45
GC-OIM-1210 54500-1210 5/8 15.90 7/8-14 1.77 45
GC-OIM-1212 54500-1212 5/8 15.90 1 1/16-14 2.95 75
One Source, One System, One Solution. www.hydraulics.goodyear.com
Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
– 21 –
COOL CLIP ™ FITTINGS
For use with GALAXY® G4890 Hose
