O-Ring Tube, Female, Swivel, 90 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OTF90-0605 54605-0605 5/16 7.90 9/16-18 1.26
32
1.10
28
GC-OTF90-0606 54605-0606 5/16 7.90 5/8-18 1.26
32
1.10
28
GC-OTF90-0608 54605-0608 5/16 7.90 3/4-16 1.42
36
1.42
36
GC-OTF90-0806 54605-0806 13/32 10.30 5/8-18 1.65
42
1.81
46
GC-OTF90-0808 54605-0808 13/32 10.30 3/4-16 1.42
36
1.42
36
GC-OTF90-1008 54605-1008 1/2 12.70 3/4-16 1.42
36
1.42
36
GC-OTF90-1010 54605-1010 1/2 12.70 7/8-14 1.65
42
1.81
46
GC-OTF90-1012 54605-1012 1/2 12.70 1 1/16-14 1.77
45
2.05
52
GC-OTF90-1210 54605-1210 5/8 15.90 7/8-14 1.65
42
1.81
46
GC-OTF90-1212 54605-1212 5/8 15.90 1 1/16-14 1.77
45
2.05
52
O-Ring Tube, Female, Swivel, 90 Block Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OTF90B-0808 54610-0808 13/32 10.30 3/4-16 0.91
23
1.97
50
GC-OTF90B-1010 54610-1010 1/2 12.70 7/8-14 0.94
24
1.97
50
GC-OTF90B-1210 54610-1210 5/8 15.90 7/8-14 0.94
24
1.97
50
O-Ring Tube, Female, Swivel, 180 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OTF180-0606 54615-0606 5/16 7.90 5/8-18 1.97
50
2.13
54
GC-OTF180-0808 54615-0808 13/32 10.30 3/4-16 2.36
60
2.13
54
GC-OTF180-1212 54615-1212 5/8 15.90 1 1/16-14 3.15
80
3.15
80
O-Ring Tube, Female, Swivel, R12 Valve
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-OTF12V-0606 54650-0606 5/16 7.90 5/8-18
1.06
27
1/4
6.35
GC-OTF12V-0808 54650-0808 13/32 10.30 3/4-16
1.22
31
1/4
6.35
GC-OTF12V-1010 54650-1010 1/2 12.70 7/8-14
1.61
41
1/4
6.35
Same as GC-OTF with
R12 Valve
– 24 –
COOL CLIP
™
FITTINGS
For use with GALAXY
®
G4890 Hose
