SAE 45 Flare, Female, Swivel, 90 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-SFFX90-0606 54765-0606 5/16 7.90 5/8-18 1.18
30
1.38
35
GC-SFFX90-0608 54765-0608 5/16 7.90 3/4-16 1.18
30
1.38
35
GC-SFFX90-0806 54765-0806 13/32 10.30 5/8-18 1.18
30
1.38
35
GC-SFFX90-0808 54765-0808 13/32 10.30 3/4-16 1.77
45
1.38
35
GC-SFFX90-1008 54765-1008 1/2 12.70 3/4-16 1.77
45
1.38
35
GC-SFFX90-1010 54765-1010 1/2 12.70 7/8-14 1.77
45
1.77
45
GC-SFFX90-1210 54765-1210 5/8 15.90 7/8-14 1.77
45
1.77
45
GC-SFFX90-1212 54765-1212 5/8 15.90 1 1/16-14 1.77
45
1.77
45
SAE 45 Flare, Male
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-SFM-0606A 54780-0606A 5/16 7.90 5/8-18
1.38
35
GC-SFM-0808A 54780-0808A 13/32 10.30 3/4-16
1.38
35
GC-SFM-1010A 54780-1010A 1/2 12.70 7/8-14
1.50
38
GC-SFM-1212A 54780-1212A 5/8 15.90 1 1/16-14
1.73
44
SAE 45 Flare, Male, 45 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-SFM45-0606A 54783-0606A 5/16 7.90 5/8-18 0.75
19
1.38
35
GC-SFM45-0808A 54783-0808A 13/32 10.30 3/4-16 0.94
24
1.38
35
GC-SFM45-1010A 54783-1010A 1/2 12.70 7/8-14 1.26
32
1.77
45
GC-SFM45-1212A 54783-1212A 5/8 15.90 1 1/16-14 1.38
35
1.77
45
SAE 45 Flare, Male, 90 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-SFM90-0606A 54785-0606A 5/16 7.90 5/8-18 1.18
30
1.38
35
GC-SFM90-0808A 54785-0808A 13/32 10.30 3/4-16 1.77
45
1.38
35
GC-SFM90-1010A 54785-1010A 1/2 12.70 7/8-14 1.77
45
1.77
45
GC-SFM90-1212A 54785-1212A 5/8 15.90 1 1/16-14 1.77
45
1.77
45
Picture Not Available
Picture Not Available
Picture Not Available
– 28 –
COOL CLIP
™
FITTINGS
For use with GALAXY
®
G4890 Hose
