GRUVLOK
®
ADVANCED COPPER METHOD
TECHNICAL DATA
COPPER FITTINGS:
Copper per ASTM B 75 and ANSI B16.22, alloy 2" - 6" C12200 8"
copper fttings are 316 Stainless Steel
PERFORMANCE DATA:
The Gruvlok Advanced Copper Method may be used with types K,
L, M and DWV copper tubing. The pressure ratings shown below are
for Gruvlok Fig. 7400 Rigidlite Coupling, Fig. 7012 Gruvlok Flange,
and Gruvlok Advanced Copper Method Fittings when used with the
specifc type of tubing indicated.
material specifications
performance data coupling advanced copper method
NOTES:
(1) Gruvlok Coupling and Gruvlok Flange size are identifed by nominal tubing size.
(2) Nominal tube wall thickness.
(3) Maximum line pressure, including surge, to which joint shall be subjected. Working pressure ratings are based on the specifed copper tubing roll grooved per
Gruvlok Copper Method Copper-Prep Specifcations.
NOTE:
For one time feld test only. The maximum joint working pressure may be increased to 1
1
/
2
times the fgure shown.
(4) Maximum end load from all internal and/or external forces, to which the joint shall be subjected.
99.9% Lead-Free!
HOUSING:
Ductile iron conforming to ASTM A 536, Grade 65-45-12
COATING:
Rust inhibiting paint — Color: orange (standard).
Hot Dipped Zinc Galvanized (optional)
Other Colors Available (IE: RAL3000 and RAL9000)
For other Coating requirements contact a Gruvlok Representative.
BOLTS & NUTS:
Heat treated, oval neck track head bolts conforming to
ASTM A 183 Grade 2 with a minimum tensile strength of 110,000 psi and
heavy hex nuts of carbon steel conforming to ASTM A 563. Bolts and
nuts are provided zinc electroplated as standard. Stainless Steel bolts
and nuts are also available.
HINGE PIN:
(Gruvlok 7012 Flange) Carbon steel
GASKETS:
Properties as designated in accordance with ASTM D2000
Grade E EPDM
(Green color code) NSF 61 Certifed
Service Temperature Range: -40°F to +190°F (-40°C to +88°C)
Recommended for water service, dilute acids, alkalies, alkaline
solutions, oil-free air and many chemical services.
NOT FOR USE IN PETROLEUM SERVICES.
LUBRICATION:
Gruvlok Xtreme
TM
lubricant only
NOTE:
Lubricant is to be applied to the entire surface, both internal and external of the
gasket. For additional important information concerning Gruvlok Xtreme
TM
Lubricant
see Gruvlok Data Sheet 3 “Gruvlok Lubricants”.
Contact a Gruvlok Representative for additional details.
TYPE “K”
ASTM B 88
1
Nominal
Tube
Size
2
Wall
Thickness
3
Max.
Joint Work.
Pressure
4
Max.
Permis.
End Load
Inches
In./mm PSI/bar
Lbs./kN
2
0.083
300
1,329
50
2.11
20.7
5.91
2
1
/
2
0.095
300
1,948
65
2.41
20.7
8.66
3
0.109
300
2,886
80
2.77
20.7
12.84
4
0.134
300
4,771
100
3.4
20.7
21.22
5
0.160
300
7,289
125
4.06
20.7
32.42
6
0.192
300
10,341
150
4.88
20.7
46.00
8
0.271
300
15,555
200
6.88
20.7
69.19
TYPE “L”
ASTM B 88
2
Wall
Thickness
3
Max.
Joint Work.
Pressure
4
Max.
Permis.
End Load
In./mm PSI/bar
Lbs./kN
0.070
300
1,329
1.78
20.7
5.91
0.080
300
1,948
2.03
20.7
8.66
0.090
300
2,886
2.29
20.7
12.84
0.110
300
4,771
2.79
20.7
21.22
0.125
300
7,289
3.18
20.7
21.42
0.140
300
10,341
3.56
20.7
46
0.200
300
15,555
5.08
20.7
69.19
TYPE “M”
ASTM B 88
2
Wall
Thickness
3
Max.
Joint Work.
Pressure
4
Max.
Permis.
End Load
In./mm PSI/bar
Lbs./kN
0.058
250
1,108
1.47
17.2
4.93
0.065
250
1,623
1.65
17.2
7.22
0.072
250
2,405
1.83
17.2
10.75
0.095
250
3,976
2.41
17.2
17.69
0.109
200
4,859
2.77
13.8
21.61
0.122
200
6,894
3.10
13.8
30.67
0.170
200
10,370
4.32
13.8
46.12
DWV
ASTM B 306
2
Wall
Thickness
3
Max.
Joint Work.
Pressure
4
Max.
Permis.
End Load
In./mm PSI/bar
Lbs./kN
–
–
–
–
–
–
–
–
–
–
–
0.045
100
962
1.14
6.9
4.28
0.058
100
1,590
1.47
6.9
7.07
0.072
100
2,430
1.83
6.9
10.81
0.083
100
3,447
2.11
6.9
15.33
0.109
100
5,185
2.77
6.9
23.06
