Imperial 90NRR
Polyester Single Jacket Rack
and Reel Hose
This interior fire protection hose is designed to replace unlined linen length for length. This polyester, SBR lined hose is ideal for interior
rack or reel service. Imperial 90NRR is available folded for standard pin racks in 50' (15m), 75’ (22.5m), and 100’ (30m) lengths. Specify
folded, coiled, or number of pins for rack (15 pins for 50’, 20 pins for 75’, or 25 pins for 100’). The standard color for Imperial 90NRR is
white. UL Label and (or) FM approval is available. UL / FM hose is rated at 150 PSI service pressure.
Imperial M
Single Jacket Polyester
Mill Hose
A heavy duty industrial mill hose, constructed of 100% spun polyester for abrasive environments and low maintenance. Designed for
water discharge and other low pressure applications such as washdown. The liner is SBR for petrochemical resistance. The standard
color for Imperial M is white.
Imperial 661
Lightweight Through-The-Weave
Washdown Hose
Imperial 661 is a layflat, lightweight, flexible maintenance hose with the durability and abrasion resistance of heavy duty rubber hose.
Imperial 661 features a unique through-the-weave, one piece construction that will not delaminate. The synthetic reinforcement is totally
encased in nitrile rubber cover and lining which is resistant to fuels, chemicals, and oil. Imperial 661 will not mildew or rot and is heat
and ozone resistant. The standard color for Imperial 661 is blue.
Imperial 661
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 225 1575 450 3150 750 5250 1-3/4 44 10 4.5 12 305
2 50 225 1575 450 3150 750 5250 2-3/16 56 15 6.8 13 330
2-1/2 65 225 1575 450 3150 750 5250 2-3/4 70 19 8.6 14 356
Imperial AG
Heavy Duty Rubber Covered
Industrial Discharge Hose
Imperial AG is a layflat, flexible water discharge hose with durability and abrasion resistance superior to conventional rubber hose.
Imperial AG features a unique one piece, through-the-weave construction, and attains its exceptional working pressure from a synthetic
woven textile. Its excellent durability is derived from a high-tensile rubber compound which completely encases the jacket. The standard
color for Imperial AG is black.
Imperial M
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1 25 125 875 250 1750 500 3500 1-1/4 32 8 3.6 13 330
1-1/2 38 125 875 250 1750 500 3500 1-11/16 43 10 4.5 14 356
2 50 125 875 250 1750 500 3500 2-3/8 60 16 7.2 15 381
2-1/2 65 125 875 250 1750 500 3500 2-11/16 68 20 9.0 15 381
3 75 125 875 250 1750 500 3500 3-3/8 86 27 12.2 17 432
5
Imperial AG
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 300 2100 600 4200 900 6300 1-13/16 45 16 7.2 15 381
2 50 300 2100 600 4200 900 6300 2-3/16 56 20 9.0 16 406
2-1/2 65 300 2100 600 4200 900 6300 2-7/8 73 25 11.3 17 432
3 75 300 2100 600 4200 900 6300 3-13/32 87 35 15.8 18 457
4 100 200 1400 400 2800 600 4200 4-5/16 110 40 18.0 19 483
6 150 200 1400 400 2800 600 4200 6-3/8 162 80 36.0 21 533
* Weight is uncoupled
Factory Mutual Approved
Imperial 90NRR
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 250 1750 500 3500 750 5250 1-11/16 43 5 2.3 12 305
