Imperial Superflow
Large Diameter Supply Hose
Imperial Superflow is a tough large diameter hose with the ability to deliver more water at a lower cost. But it doesn’t stop there. It is
lightweight, compact and durable with a high resistance to oils, chemicals, ozone and heat. Its tough, high tensile cover and lining,
permanently interlocked with the synthetic reinforcement, provide greater abrasion resistance while being snag-proof, kink resistant, and
immune to mildew or rot. U.L. labeling is available on 4” (100 mm) and 5” (125 mm) only. The standard color for Imperial Superflow is
yellow.
Imperial Superflow
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 100' (30m) 100' (30m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
3 75 300 2100 600 4200 900 6300 3-13/32 87 70 31.5 25 635
4 100 225 1575 450 3150 675 4725 4-5/16 110 90 40.5 24 610
5 125 200 1400 400 2800 600 4200 5-3/8 137 109 49.1 27 686
7
Imperial Superlite
High Rise Fire Hose
Imperial Superlite is an ultra-lightweight, maneuverable, nitrile rubber hose designed specifically for fighting fires in high rise buildings.
The lightweight through-the-weave construction is heat and puncture resistant, kink resistant and has low friction loss. The rubber cover
prevents water from penetrating the reinforcement thus minimizing the weight of the hose when in service. The standard color for
Imperial Superlite is blue.
Imperial Superlite
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 50' (15m) 50' (15m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1-1/2 38 300 2100 600 4200 900 6300 1-3/4 44 11 5.0 13 330
2 50 300 2100 600 4200 900 6300 2-3/16 56 18 8.1 14 356
2-1/2 65 300 2100 600 4200 900 6300 2-3/4 70 20 9.0 15 381
Imperial 629
Rubber Covered
Through-The-Weave Forestry Hose
Nitrile rubber covered forestry hoses that require no washing or drying and are mildew resistant. A protective rubber covering resists
burns and prevents damage of the textile reinforcement which may be caused by abrasion or hot embers. The standard color is high
visibility yellow. There is a minimum order quantity for 1-1/2” size.
Imperial F187
Polyester Single Jacket
Plastic Lined Forestry Hose
A lightweight polyester jacket, polyurethane lined forestry fire hose that meets the USDA-US Forest Service Specification 5100-187. The
standard color for Imperial F187 is white.
Imperial 629
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 100' (30m) 100' (30m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1 25 300 2100 600 4200 900 6300 1-1/4 31.8 10 4.5 16 406
1-1/2 38 300 2100 600 4200 900 6300 1-11/16 42.9 17 7.5 18 457
Imperial F187
Pressure Weight* Coil Diameter
Size Service Proof Burst Bowl Size 100' (30m) 100' (30m)
inch mm psi kPa psi kPa psi kPa inch mm lbs. kg inch mm
1 25 300 2100 600 4200 900 6300 1-1/4 31.8 7.5 3.4 14 356
1-1/2 38 300 2100 600 4200 900 6300 1-3/4 45 13.5 6.1 16 406
* Weight is uncoupled
Non-standard diameters available by special arrangement
