PRIME MOVER ™ COGGED
These belts have a
precision cogged profile
base which is designed
for uniform stress
distribution, superior heat
dissipation and greater
flexibility. They provide
higher horsepower
capacity for exceptional performance on small
diameter sheaves using A, B, and C Section drives.
Prime Mover Cogged Belts are available in AX, BX
and CX wedge size dimensions and come in a wide
variety of lengths.
Their extra duty wedge construction is specifically
designed to fit the sheave groves exactly, which
allows maximum wedging action. These belts are built
with tough polyester tensile members, bonded cord
and neoprene rubber to prevent separation, improve
cord stability and resist fatigue and shock loads.
Maxipower belts are also oil and heat resistant and
static conducting.*
Thermoid® V-Belts
PRIME MOVER BANDED
This banded belt is a
unitized set of premium
construction belts. A
vulcanized band is
utilized to form a belt set
in which the individual
V’s are spaced to permit
operation in MPTA stan-
dard groove belt sheaves. This design prevents belt
whip and turnover under pulsating and shock loads.
B and C cross sections up to 200" I.C. are single cord
construction which offers flexibility for operating over
small diameter pulleys and short distances between
pulleys at higher speeds. All D cross sections, B and C
sizes over 200" I.C. are multi-cord construction, suited
for operation at longer distances. They are available
in B, C and D cross-sections that are oil and heat
resistant and static conducting.*
MAXIPOWER BANDED
Maxipower Banded V-belts
are molded with a
vulcanized band into a
unitized belt set. The
individual Y’s are spaced to
permit operation in MPTA
standard groove 3V, 5V
and 8V sheaves. They have
been engineered for difficult applications where lateral
vibration and heavy shocks often cause individual
belts to whip or turnover. Maxipower Banded belts are
oil and heat resistant and static conducting.*
MAXIPOWER COGGED BANDED
Maxipower Cogged
Banded V-belts are cut
from a vulcanized sleeve
into a unitized belt set.
The individual V’s are
spaced to permit
operation in MPTA
standard groove 3V and
5V sheaves. They have been engineered for difficult
applications where small sheaves, lateral vibration
and heavy shocks often cause individual belts to whip
or turnover. You can use sheaves as small as 2.2" in
diameter. The unique notched construction distributes
bending stress uniformly — and also provides
superior heat dissipation. These belts are oil, ozone,
and heat resistant and static conducting.*
Thermoid® Banded Belts
For Assistance: 800/433-8208 or E-Mail: hbdbelts@hbdelgin.com
POWERPLUS MAXIBAND
PowerPlus Maxiband
belts are designed for
high horsepower, high
tension and severe
shock load applications
such as dredge pumps,
hammer mills, pile
drivers and steel billet
grinders. This belt delivers as much as 50% more
horsepower than ordinary belt setups. Super tough
Kevlar cords with maximum internal adhesion have far
more heat resistance and far less stretch than other
cords. The cover is rugged, woven 2-ply, specially
processed for maximum adhesion, and to protect the
carcass from abrasion, heat, and oil, and to prevent
static buildup. A premium chloroprene rubber cushion
section resists compression, heat, oil and fatigue.
This keeps the belt flexing smoothly and easily as it
passes over the sheaves. An oil resistant insulation
section transfers the belt load to the Kevlar cords.
