SOLVE TOUGH MAINTENANCE
PROBLEMS ECONOMICALLY
Utilizing the same basic frame as the Turn Clean™ the
patented VAN GORP® SNAP-BACK® Pulley eliminates
virtually every maintenance problem on conveyor systems
handling wet, sticky or abrasive materials. Its exclusive
design allows the pulley to automatically clean itself by
reducing build-up, belt wear and eventually maintenance
and downtime problems. Here’s how it works:
High tensile strength rubber or Urethane lagging, encased
in a steel jacket, displaces upon belt contact. When belt
contact is broken, the rubber actually “snaps back” to its
original height. Ideal in snub and bend applications where
the pulley comes into contact with the belt’s carrying side.
This unique feature assures minimum belt wear and
maximum cleaning efficiency for years of maintenance-free
service. Lagging can be easily and economically changed
in the field by merely installing a new channeled rubber
insert within the heavy-duty, 7-gauge steel jacket channel.
Snap-Back ® Wing Pulleys
Rubber Snap-Back®
Pulley Diameter
Crown Face
Face Width
Hub Type and Size
WR 24 C 57 XT45
Part Number Example
Urethane Snap-Back®
Pulley Diameter
Crown Face
Face Width
Hub Type and Size
WU 20 C 51 XT30
