Metal Clad Wipers
These rod wipers are molded from urethane and encased in a heavy duty metal case. This gives them exceptional
abrasion resistance and outstanding endurance under difficult operating conditions. Highly effective in removing dirt and
contaminants from the rod. The dimensions for Metal Clad Wipers stocked by American Packing are listed below. For
availability of additional sizes not listed, please inquire.
A
B
C
A
B
C
Part
Number
Rod
Diameter
(inches)
Bore
Diameter
(inches)
Height
(inches)
Part
Number
Rod
Diameter
(inches)
Bore
Diameter
(inches)
Height
(inches)
MCW0625
5/8
1 1/8
5/16
MCW3000
3
3 1/2
5/16
MCW0750
3/4
1 1/4
5/16
MCW3003
3
3.751
3/8
MCW0875
7/8
1 3/8
5/16
MCW3004
3
4
1/2
MCW1000
1
1 1/2
5/16
MCW3250
3 1/4
3 3/4
5/16
MCW1125
1 1/8
1 5/8
5/16
MCW3253
3 1/4
3 7/8
5/16
MCW1250
1 1/4
1 3/4
5/16
MCW3254
3 1/4
4 1/4
1/2
MCW1252
1 1/4
2 1/16
3/8
MCW3500
3 1/2
4
5/16
MCW1375
1 3/8
1 7/8
5/16
MCW3502
3 1/2
4 1/8
5/16
MCW1500
1 1/2
2
5/16
MCW3505
3 1/2
4 1/2
1/2
MCW1502
1 1/2
2 1/8
5/16
MCW3750
3 3/4
4 3/8
5/16
MCW1504
1 1/2
2 1/4
3/8
MCW3754
3 3/4
4 1/2
5/16
MCW1625
1 5/8
2 1/8
5/16
MCW4000
4
4 5/8
5/16
MCW1750
1 3/4
2 1/4
5/16
MCW4002
4
4 3/4
5/16
MCW1875
1 7/8
2 3/8
5/16
MCW4005
4
5
1/2
MCW2000
2
2 1/2
5/16
MCW4250
4 1/4
4 3/4
3/16
MCW2007
2
2 3/4
3/8
MCW4500
4 1/2
5 1/8
5/16
MCW2250
2 1/4
2 3/4
5/16
MCW4506
4 1/2
5 1/4
5/16
MCW2253
2.250
2.997
3/8
MCW4507
4 1/2
5 1/2
1/2
MCW2375
2 3/8
2 7/8
5/16
MCW5000
5
5 5/8
5/16
MCW2500
2 1/2
3
5/16
MCW5005
5
5 3/4
5/16
MCW2503
2 1/2
3 1/4
3/8
MCW5500
5 1/2
6 1/8
3/8
MCW2625
2 5/8
3 1/8
1/4
MCW5506
5 1/2
6 1/4
5/16
MCW2750
2 3/4
3 1/4
5/16
MCW5750
5 3/4
6 3/8
3/8
MCW2753
2 3/4
3 1/2
3/8
MCW6000
6
6 5/8
3/8
