Pressure Drop - psig
Valve Size
Flow (Water) - gpm
Dimensions/Weights — Butterfly Valve
Nominal
Size
Copper
Tube
Diameter
Dimensions
Weight
A
B
C
D
In.
In./mm In./mm In./mm In./mm In./mm Lbs./kg
2
1
/
2
2.625
66.7
3.77
96
6.23
158
2.76
70
10.8
274
5.90
2.68
3
3.125
79.4
3.77
96
6.74
171
3.13
80
10.8
274
6.60
2.99
4
4.125
104.8
4.63
118
8.60
218
4.10
104
10.8
274
11.00
4.99
5
5.125
130.2
5.27
134
10.22
260
5.10
130
10.8
274
17.60
7.98
6
6.125
155.6
5.27
134
11.10
282
6.12
155
10.8
274
21.60
9.80
Valve Body:
Bronze to ASTM B584 C90500 (88-10-0-2) certifed to ANSI/NSF 61 for
use in cold +86°F (+30°C) and hot +180°F (+82°C) potable water system.
Disc:
Ductile iron to ASTM A536 Gr. 65-45-12 encapsulated with EPDM.
Grade “E” EPDM: Service temperature range: -40°F to +230°F (-40°C
to +110°C). Recommended for water service, diluted acids, alkaline
solutions, and oil-free air.
Not recommended for use in petroleum applications.
Upper & Lower Shafts:
Stainless Steel Type 416 of ASTM A582.
Butterfly Valve
The lever handle bronze body butterfy valve is designed for use with grooved
copper tubing (CTS), fttings and couplings. This valve features a 10 position lever
handle, bronze body and EPDM rubber encapsulated dual-seal disc. Both bronze
valve body and the EPDM rubber disc obtained certifcation to ANSI/NSF 61
for use in potable water systems, and is rated to 300 PSI (20 bar).
material specifications
Butterfly Valve Torque Data
Nominal Size
Operating Torque
In.
N-M
Lbs/Ft.
2
1
/
2
12.5
9
3
18.0
13
4
43.0
32
5
62.0
46
6
72.0
53
Values for flow of water at +60°F (+16°C)
Q C
v
=
D
P
Where: C
v
= Flow coefficient
Q = Flow (GPM)
D
P = Pressure drop (psi)
D
A
O.D.
C
B
GL-2.10
