VariFlex™ Product Specifications |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Application
A good-quality, economical general purpose hose for industrial air service, compressor lines, pneumatic tools, low-pressure spray and many other applications where the need for oil resistance is moderate Non-conductive, minimum electrical resistance greater than 1 megohm per inch of length of hose at 1000 volts DC Available in 200 and 300 psi working pressures Construction> Tube Nitrile synthetic rubber, ARPM Class A (High Oil Resistance) > CoverRed, blue or black Chemivic synthetic rubber, ARPM Class A (High Oil Resistance) > ReinforcementSpiral synthetic yarn (3/16"-1 1/2"), braided synthetic yarn (2") Temperature Range-20°F to 210°F (-29°C to 99°C) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Packaging
90% one-piece reels up to 1" 3/16"-3/4" – 500' reels, maximum 3 pieces, 50' increments 1" – 450' reels, maximum 3 pieces, 50' increments 1 1/4" – 400' reels, maximum 3 pieces, 50' increments 1 1/2" – 300' reels, maximum 3 pieces, 50' increments Coupled assemblies available in 1/4", 3/8" and 1/2" in red BrandingExample: VariFlex™ Non-conductive 1/2" (12 7 mm) 200 psi WP Made in USA Continental ContiTech CouplingsRefer to the ContiTech Industrial Hose Assembly Manual for crimp specifications Coupled assemblies available Order CodesSee next page |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Hose design ratio (burst pressure) 4:1. |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Hose design ratio (burst pressure) 4:1. |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Add to Quote Cart
Applications
Variflex Hose is used in industrial transfer, handling, and support operations where reliable product performance and practical sourcing support are required.
Materials Overview
Material selection varies by media, environment, fitting interface, and service conditions. Existing product details above remain the primary source for specifications.
Selection Guidance
Match product configuration to your operating media, routing constraints, connection standards, and maintenance expectations. Use the quote cart to submit project requirements.
Installation and Maintenance Notes
Follow manufacturer handling practices, inspect components before installation, verify connection compatibility, and schedule routine inspections based on your service cycle.
Industries Served
Industrial manufacturing, processing, utilities, construction, transportation, and maintenance operations.
Technical Specifications
| Existing Technical Claim (Verbatim) |
|---|
| 1 megohm per inch of length of hose at 1000 volts DC Available in 200 and 300 psi working pressures Construction > Tube Nitrile synthetic rubber, ARPM Class A (High Oil Resistance) |
| 200 Order Codes: 569-005 (black), 569-007 (red), 569-036 (blue) SAP # ID Nom. |
| 300 Order Codes: 569-006 (black), 569-008 (3/16"-1 1/2" red), 569-037 (blue), 536-037 (2" red), 536-006 (2" black) SAP # ID Nom. |
