APPLICATION: Ortac- (Oil Resistant Tube and Cover) is our most popular premium-quality multipurpose hose. Used in the most abusive industrial applications, Ortac will handle air, oil, water, kerosene and some chemicals. Nonconductive, minimum electrical resistance greater than one (1) megohm per inch of hose length; at 1000 Volts DC. Available In 250, 300 and 400 PSI working pressures. NOTE: Ortac 400 Yellow is USMSHA approved.
CONSTRUCTION TUBE: Nitrile synthetic rubber, RMA Class A(high oil resistance)
COVER: Red or Yellow Carbryn synthetic rubber, RMA Class A (high oil resistance)
REINFORCEMENT: Spiral synthetic yam, 2" is braided
TEMPERATURE: -20F to 190F (-29C to 88C)
PACKAGING: 3/16"-3/4"
3/16"-3/4" 500' reels, maximum 3 pieces, 50' Increments
1" 450' reels, maximum 3 pieces, 50' inClements
1 1/4 " 400' reels, maximum 3 pieces, 50' inClements
1 1/2" 300' reels, maximum 3 pieces, 50' inclements
2" 200' cartons, maximum 3 pieces, 50' inclements
BRANDING: Example: 11/2" (38.1 mm) Ortac 300 psi WP. Made in USA Goodyear.
COUPLINGS: Contact fitting manufacture for prolK!r fitting recommendation and coupling proced ure.
|
