Series A1730 Flexible FDA Polyethylene Hose

A flexible food grade hose for those applications in which a PVC hose may not be suitable.
Construction:
   •Tube – 82 Shore “A” polyethylene in compliance with FDA(04) and RoHS(15) requirements.
   •Reinforcement – High tensile strength yarn.
   •Cover – 68 Shore ”A“ flexible polyethylene cover in compliance with FDA(04) and RoHS(15) requirements.
Features:

  • Flexible non-chlorinated non-PVC hose.
  • Can be incinerated without harmful emissions.
  • Light weight.
Applications:
  • Applications involving radiation or other contaminants that require disposal of the hose after use.
  • Food transfer.

Nominal Specification

Series No. Series Code Nominal ID Nominal OD MAX. Working Pressure (PSI) Strength Length Approx Wt. Per Pkg.
In mm In mm @ 70°F (20°C) @ 122°F (50°C Full Coil Cut Length Full Coil Cut Length
A1730041/46.5.46011.715075500 ft.100 ft.22.5 lbs.4.5 lbs.
A1730063/89.5.59315.115075300 ft.100 ft.19.8 lbs.6.6 lbs.
A1730081/212.7.74018.815075300ft.100 ft.17.3 lbs.9.1 lbs.

Series A3236 High Purity Non-Toxic LLDPE Water Hose

A flexible, non-contaminating food grade hose that is ideal for use in food, beverage and water applications.
Construction:
   •Tube – Special co-extruded tube with the inner contact surface meeting applicable FDA(04), NSF(12) and RoHS(15) requirements.
   •Reinforcement – High tensile strength yarn.
   •Cover – Blue EVA copolymer . . . complies with FDA(04) and RoHS(15) requirements.
Features:

  • Extremely light weight.
  • Good resistance to U. V. and weather aging.
  • Exceptionally low hydrocarbon extraction into water, as compared to the EPA MCL’s (maximum contaminant levels) for drinking water.
  • Extremely low hydrocarbon absorption from contaminated water samples.
  • Excellent low temperature flexibility.
  • Excellent chemical resistance.
  • Silicone-free.
  • One-piece lengths.
  • Opaque jacket reduces tendency for algae growth in warm, sunny applications.
Applications:
  • Transfer of food, beverages and water.
  • Transfer of deionized water.
  • Water sampling.
  • Water bottling equipment.
  • Water transfer lines for semiconductor manufacturing, where applicable.
  • Temporary residential water supply lines.
  • Environmental clean-up applications involving water and chemicals.

Nominal Specification

Series No. Series Code Nominal ID Nominal OD MAX. Working Pressure (PSI) Strength Length Coil Approx Wt. Per Pkg.
In mm In mm @ 70°F (20°C) @ 122°F (50°C
A3236081/212.7.75019.1200100300 ft.33 lbs.
A3236123/419.11.12528.6200100300 ft.68 lbs.
A323616125.41.37534.915075200 ft.59 lbs.

Series K6155, K6158 High Purity Non-Toxic PVC Potable Water Hose

A High Purity non-conductive hose with colored jacket which is ideal for potable water and deionized water transfer.
Construction:
   •Tube – Clear PVC compound, formulated in compliance with FDA(03) and NSF(11)(13) criteria
   •Reinforcement – High tensile strength yarn.
   •Cover – Non-toxic PVC compound, available in two solid colors: K6155 – White and K6158 – Grey. Additional non-toxic colors (Red, Black, Blue, Green and Sand) are available on a special order basis.
Features:

  • Made with PVC compounds certified under NSF-51/NSF-61.
  • White or gray jacket to reduce tendency for algae growth and U. V. degradation in warm sunny applications.
  • Non-marking cover.
  • Non-perforated cover.
  • Non-conductive compounds.
  • Silicone-free.
  • One-piece lengths.
  • RoHS(15) compliant
Applications:
  • Transfer of potable water.
  • Transfer of deionized water.
  • Induction welding tubing lines.
  • Temporary residential water supply lines.
  • Water transfer lines for semiconductor manufacturing, where applicable.
  • Applications requiring a non-conductive hose.

Nominal Specification

Standard Stock Colors Size Code Nominal ID Nominal OD MAX. Working Pressure (PSI) Strength Length Coil Approx Wt. Per Pkg.
K6155 White K6158 Grey In mm In mm @ 70°F (20°C) @ 122°F (50°C
063/89.5.59415.1225125300 ft.27 lbs.
081/212.7.75019.1200100300 ft.40 lbs.
123/419.11.03126.215085200 ft.43 lbs.
16125.41.30033.012575200 ft.59 lbs.
241 1/238.11.93849.210050100 ft.64 lbs.
