Brewline Hose

Plicord® Brewline®

Product Specifications

Application

Plicord® Brewline® is primarily for liquid transfer. It is a quality discharge hose designed specifically for the highly demanding service of transferring non-oily liquid products in wineries and breweries.

Temperature Range

-40°F to 220°F (-40°C to 104°C)

Branding

Example: Continental ContiTech Plicord® Brewline® 250 psi FDA 3-A USDA

Couplings

Contact fitting manufacturer for proper fitting recommendation and coupling procedure.

Order Codes

549-003 (red Microban®)
549-885 (red)

Construction
> Tube

White chlorobutyl rubber (FDA/USDA compliant and conforms to 3-A Sanitary Standard 18-03)

> Cover

Red EPDM with a white spiral stripe (wrapped impression)

> Reinforcement

Spiral-plied synthetic fabric, 4 plies to 1 1\2" ID; 6 plies over 1 1/2" ID

Packaging

100' lengths, coiled and poly-wrapped

SAP#	ID		Nom. OD		Max. WP		Bend Radius		Weight
Black	in.	mm	in.	mm	psi	MPa	in.	mm	lb./ft.	kg/m
20020324	3/4	19.1	1.34	34.0	250	1.72	20	508	0.54	0.80
20020327	1	25.4	1.69	42.9	250	1.72	20	508	0.81	1.21
20032192	1¼	31.8	2.00	50.8	250	1.72	20	508	1.05	1.56
20020335	1½	38.1	2.23	56.6	250	1.72	20	508	1.19	1.77
20020341	2	50.8	2.88	73.2	250	1.72	20	508	1.86	2.77
20020345	2½	63.5	3.51	89.2	250	1.72	20	508	2.66	3.96
20020348	3	76.2	4.09	103.9	250	1.72	20	508	3.57	5.31
20020352	4	101.6	5.31	134.9	250	1.72	20	508	5.43	8.08
